This is a recessed ground light with a round bezel with a diameter of 140mm. Inside in a 10.5 watt LED array providing 1,000 lumens, making it well suited for uplighting facades to around 20 feet.

The fitting will provide upward lighting and is very popular for wall washing because of the 60-degree beam angle and external adjustment.

Engineered from aluminium with a Grade 304 brushed stainless steel bezel and unlike many ground lights this does not need to be opened when installed on site, it has 1 metre long flying lead for external electrical connection, avoiding water ingress and installation errors. Not suitable for a marine environment.

Supplied with a burial pot for installation into concrete only.

Cut-out diameter typically 132mm (dependent on your installation), requires a depth of at least 160mm for the fitting to sit correctly.

IP67 providing protection against strong water jets and immersion.

Supplied with a 10.5 watt LED chip giving 1000 lumens. Available in either 4000°k neutral white or 3000°k warm white.

External angle adjustment

To adjust, remove three screws from the bezel and lift the luminaire from the burial pot. Adjust the light to your prefered angle, drop back into place and screw back the bezel. The angle range can turn left or right by 20º.

Number Of Lamps	1
Lamp Type	Long Life LED Light Source
Part L Compliant Luminaire	No
Lamps Included	Yes
Dimmable?	No
Max Wattage	6w
Height	128mm
Diameter	108mm
Depth/Projection	5mm
Cut-Out Diameter	135mm
Construction	Stainless Steel Brushed
Wiring Details	Class 1 - Requires an Earth Connection
IP Rating	IP67
Kelvin	4000°K - Neutral White

Are you able to replace the bulb once the light fitting is in the ground?
No, these fittings are fitted with a 10.5 watt LED chip which has long life span and is not replaceable as such.

Does this item have an umsug code ?
There is no such code listed on the specification.

Are the bulbs replaceable if not is there a GU10 equivalent?
This LED is integrated and non replaceable. We do have a GU10 version, Product Ref: 6317, however, this is not adjustable.

Hi. I am looking to create the same effect as product 30585. Are you able to advise if this product will do the job?
If using a bright LED lamp if should create a similar effect. However it will not project as high up the wall.

Can this product be buried in the soil/bedding area of garden?
This fitting is to be installed into drive ways or concrete walk ways. For lighting in soil areas we would recommended using spike lights.
