Bathroom Chrome 3 Light Spot Bar for Wall or Ceiling

Fully Adjustable Light Fitting

Suitable for Zone 2 - splash proofClass 2 – This fitting is double insulated and does not require an earth.Yes, this product is dimmable - See the specifications tab for more detailsSuitable for Bathroom Zones 2 and 3Bulbs Not Included

Product Ref: 3747

£102.94 inc VAT

This is a polished chrome triple light bar suitable for bathroom installation but can be used elsewhere if preferred. The fitting pays attention to the GU10 lamp and, instead of having it hidden, the lamps are on show but protected by thin frosted glass.

This fitting is suitable for installation on ceilings or walls. Great if used above a mirror and the adjustable lamp heads can be used to project light as required.

IP44 rated providing protection from entry by solid objects with a diameter or thickness greater than 1.0mm and protection from splashed water.

Suitable for zones 2 and 3 Class 2 double insulated.

Designed for use with GU10 35 watt maximum lamps.

Number Of Lamps3
Lamp TypeGU10 Base Mains Lamps
Lamps IncludedNo
Dimmable?Yes - on standard dimmer
Max Wattage35w
Total Wattage105w
Width70mm
Length500mm
Depth/Projection146mm
ConstructionPolished Chrome
Wiring DetailsClass 2 - Double Insulated - Requires no Earth Connection
IP RatingIP44
PDF Document(s)View PDF
GU10 Dimmable COB Daylight White - 6W LED Lamp
JGGUCOB6DCW
GU10 Osram 2700ºk 5.3w Dimmable LED
RADPPAR1650ADV2700
GU10 Osram 3000ºk 5.3w Dimmable LED
RADPPAR1650ADV30
GU10 Osram 4000ºk 4.6w Dimmable LED
RADPPAR1650ADV40
GU10 COB Warm White - 5W LED Lamp
JGGUCOB5WW
GU10 COB Daylight White - 5W LED Lamp
JGGUCOB5CW
GU10 4.6 Watt Warm White Lamp - Osram LED Star
RADPPAR1650
Click here to choose your bulbs

Can you tell me how to get the glass `shade` off to change the bulb please?
There is a small allen key head grub screw on the main tube of each head, undo this and the shade will pull off

Would the 1W coloured GU10 LED bulbs also fit this lamp?
Yes, the 1 watt LED lamps will comfortably fit.

I was looking to use this with an LED GU10 bulb, as I have experienced an GU10 bulb explode and would not like to take the risk of this again. Firstly would LED bulbs be a problem and secondly would the frosted glass dim the brightness and if so could the glass be left out of the fitting?
You can use a LED lamp in this fitting - just ensure it is the same size (length) as a standard halogen GU10 base lamp i.e.our Ideal Fit LED lamp. The glass on this fitting is clear at the front and frosted at the side - so it doesn`t affect the light going forward.

Availability: IN STOCK 2-3 working day dispatch
We offer free delivery on orders over £50 to most UK Mainland Addresses
Product Code
Product Title

Price
Quantity
Choose your product
MIK6137
Chrome 3 Light Spotlight Suitable for Bathrooms
You save £53.72
£102.94
£85.79 exc VAT
