LED CCT Oversize Downlight - Cover Holes from 55mm to 205mm

Ideal for Shallow Ceiling Voids - 4 Sizes Available and Optional Chrome Or Black Bezels

Offers no protection from splashed or sprayed waterClass 2 – This fitting is double insulated and does not require an earth.No, this product is NOT dimmableBulbs IncludedIncludes integral driver/transformer suitable for 230 - 240v supply

Kelvin Chart

Product Ref: 6249

From £19.09 inc VAT

Need to replace large old fashioned mains downlights? Struggling to find something that will fit? Look no further, this is the fitting for you.

This CCT LED downlight is available in 4 sizes. Between them, they can fit cutout holes from 55mm all the way up to 250mm. Each light comes with adjustable brackets bracket. Match the bracket to your cutout, screw to the ceiling and attach the light. Simple, quick and easy.

Recessed or surface mounted, you do not have to use the bracket to cover a hole these can be attached to any ceiling. This makes them ideal for low ceilings or where space is a real issue.

What is CCT? CCT means you can pick the colour temperature, there are 3 options available - 3000K, 4000K and 6000K.

On the fitting there are four options, The colour temperatures and one called "switch" With the switch option you control the colour output by your mains switch, to do this  Switch off and on again repeatedly until the desired colour temperature is achieved, then switch off and leave off for 5 seconds to save the colour setting.

Ideal replacement for old PL downlights that you find in commercial areas.  These are more energy saving, Long lamp life and maintenance is next to nothing compared to the old PL fixtures.

Edge-lit technology means there are no dark spots and reduced glare.

Optional easy to fit magnetic bezels are offered in Matt black, brushed or polished chrome.

6w CCT 140mm Diameter
Cutout: 55m - 100mm
Lumens - 3000k - 400, 4000k - 430, 6000k - 410
Equivalent Wattage: 40w

12w CCT 165mm Diameter
Cutout: 55m - 125mm
Lumens - 3000k - 850, 4000k - 940, 6000k - 920
Equivalent Wattage: 60w

18w CCT 217mm Diameter
Cutout: 55m - 175mm
Lumens - 3000k - 1300, 4000k - 1400, 6000k - 1360
Equivalent Wattage: 100w

24w CCT 290mm Diameter
Cutout: 55m - 250mm
Lumens - 3000k - 1940, 4000k - 2140, 6000k - 2100
Equivalent Wattage: 150w

Number Of Lamps1
Lamp TypeLong Life LED light source
Lamps IncludedYes
Dimmable?No
Depth/Projection15mm
ConstructionPolycarbonate
Wiring DetailsClass 2 - Double Insulated - Requires no Earth Connection
IP RatingIP20
DriverIncludes integral driver/transformer suitable for 230 - 240v supply
PDF Document(s)View PDF
Availability: Typically dispatched in 2-4 days
We offer free delivery on orders over £50 to most UK Mainland Addresses
Product Code
Product Title

Price
Quantity
Choose your product
6 Watt - 140mm Diameter
MLCPL6CT
6 Watt Flat Profile LED Downlight - Switchable Colour Temperature
£19.09
£15.91 exc VAT
MLCPL6BC
Brushed Chrome Bezel for 6w fixture
£4.25
£3.54 exc VAT
MLCPL6PC
Polished Chrome Bezel for 6w fixture
£4.25
£3.54 exc VAT
MLCPL6MB
Matt Black Bezel for 6w fixture
£4.25
£3.54 exc VAT
12 Watt - 165mm Diameter
MLCPL12CT
12 Watt Flat Profile LED Downlight - Switchable Colour Temperature
£22.89
£19.08 exc VAT
MLCPL12BC
Brushed Chrome Bezel for 12w fixture
£5.43
£4.53 exc VAT
MLCPL12PC
Polished Chrome Bezel for 12w fixture
£5.43
£4.53 exc VAT
MLCPL12MB
Matt Black Bezel Bezel for 12w fixture
£5.43
£4.53 exc VAT
18 Watt - 217mm Diameter
MLCPL18CT
18 Watt Flat Profile LED Downlight - Switchable Colour Temperature
£27.82
£23.18 exc VAT
MLCPL18BC
Brushed Chrome Bezel for 18w fixture
£6.44
£5.37 exc VAT
MLCPL18PC
Polished Chrome Bezel for 18w fixture
£6.44
£5.37 exc VAT
MLPL18MB
Matt Black Bezel for 18w fixture
£6.44
£5.37 exc VAT
24 Watt - 290mm Diameter
MLCPL24CT
24 Watt Flat Profile LED Downlight - Switchable Colour Temperature
£39.25
£32.71 exc VAT
MLCPL24BC
Brushed Chrome Bezel for 24w fixture
£8.71
£7.26 exc VAT
MLCPL24PC
Polished Chrome Bezel for 24w fixture
£8.71
£7.26 exc VAT
MLCPL24MB
Matt Black Bezel for 24w fixture
£8.71
£7.26 exc VAT
