Covered Black Wall Lantern with PIR

Name: Covered Black Wall Lantern with PIR
Brand: Lighting Styles
SKU: 2032
Price: 75 GBP
Availability: InStock
Rating: 8.8 (4 reviews)

Black Finish

Protected from water spray from all directions

Class 1 – This fitting will require an earth connection.

Product Ref: 2032

£75.00 inc VAT

Description

Simple standing wall lantern in powder coated aluminium with a clear acrylic shade.

This light will give good even illumination and allow you to see the entrance to your property with its PIR sensor action whilst also providing some security lighting.

Looks great with one of our decorative long life lamps.

PIR range 8.0 metres over 180 degrees.

Time on adjustable from 5 seconds to 8 minutes. No override on this model.

IP44 providing protection of sprayed water from any direction.

Specification

Number Of Lamps	1
Lamp Type	E27 (ES) Base Mains Lamps
Part L Compliant Luminaire	No
Lamps Included	No
Dimmable?	No
Max Wattage	75w
Width	240mm
Height	480mm
Depth/Projection	290mm
Construction	Cast Aluminium - Painted
Wiring Details	Class 1 - Requires an Earth Connection
IP Rating	IP44

Bulbs

	E27 LED 60mm ES Frosted Lamp - 8W 750 Lumens - MLGLS8ESO
	E27 1800k 6w Dimmable LED Squirrel Vintage Lamp 450 Lumens - SAM76803
	E27 5W Tube Amber Glass Lamp 360 Lumens - CITCBL700172
	E27 Vintage LED 4w Squirrel Lamp JGVINST64ESD
Click here to choose your bulbs

Frequently Asked Questions

Are you able to supply a bracket to mount this lamp - HRD7235750 - on the corner of a building.
Yes, we offer this, the ref. code is HRD448750. This has a number of holes that fit most exterior lanterns mounting patterns but can also be easily drilled if the current holes are not suitable.

Can this lamp be wired with cable which runs along wall rather than coming out of wall directly into back of lamp unit?
Yes by creating a notch in the bottom of mounting plate with a file or similar.

Your product details state that the time-on can be set anywhere from 5 seconds to 8 minutes. However, the instructions supplied with the lamp don````t mention this. How do I change the default 5 sec setting?
The time adjustment is located on the underside of the PIR sensor, it`s a small black flathead screw. This allows you to change the time setting, along with a sensor dial next to it to control the PIR sensor range.

Can you tell me if the PIR sensor has a day/night element as well as movement (ie it doesn````t come on in the day time!)?
This fitting would not come on in the day, so in short, Yes.

Is it possible to adjust the range and/ or the sensor angle on this lamp?
The angle of the PIR is 180º and can not be adjusted, the range is 8 meters.

Is it possible to purchase a replacement sensor assembly for this light ? If so, what are the dimensions?
Replacement sensors are unfortunately not available for these fittings. Short of replacing your entire fitting your best solution is to bypass your current PIR sensor and install a remote PIR. See our accessories section for a choice of remote PIR sensors.

Availability: Typically dispatched in 4-7 days
