Scandinavian Louvre Design Light with PIR Sensor

Name: Scandinavian Louvre Design Light with PIR Sensor
Brand: Lighting Styles
SKU: 4525
Price: 68.36 GBP
Availability: InStock
Rating: 8.6 (6 reviews)

Copper, Galvanised, Stainless or Black Paint

Protected from water spray from all directions

Class 1 – This fitting will require an earth connection.

Product Ref: 4525

From £68.36 inc VAT

Description

This wall light is modern in its design and suitable for use in many garden lighting applications. Available in 4 finishes, black, copper, stainless steel and galvanised steel.

PIR sensor has range of 8 metres with a 100 degree angle of detection.

PIR is preset at 15 lux (dusk) and when triggered switches on the light for 1 minute.

Has a manual override operation which can be activated by switching the light off-on-off-on by using the fused spur switch.

This will switch the light on for a period of 5 hours.

Dimensions: H:230mm, W:250mm.

Wall base Diameter: 90mm

This fitting requires a single E27 Edison screw light bulb (Max 60 Watts)

IP54 Rated making this weatherproof.

Specification

Number Of Lamps	1
Lamp Type	E27 (ES) Base Mains Lamps
Lamps Included	No
Max Wattage	60w
Total Wattage	60w
Height	230mm
Depth/Projection	260mm
Construction	Steel - Powder Coated
Wiring Details	Class 1 - Requires an Earth Connection
IP Rating	IP54

Bulbs

	E27 7w LED Silver Crown LED Lamp 806 Lumens - CITCBL700200
	E27 LED 60mm ES Frosted Lamp - 8W 750 Lumens - MLGLS8ESO
	E27 Standard LED Filament GLS 6w Lamp 620 Lumens - MLGLS6ESC
	E27 Radium 30w Ecoplus GLS lamp (40w equivalent) RAD22318031
	E27 Radium 46w Ecoplus GLS lamp (60w equivalent) RAD22318032
	E27 Long Life Decorative Lamp - 60w Tube HRD690060
	E27 4w LED Metallic Silver Crown GLS Lamp OBCIT70012800A
	E27LED Lamp - Dusk Till Dawn Sensor Built In LSE22198
Click here to choose your bulbs

Frequently Asked Questions

Can the sensitivity (lumen level or PIR sensitivity) be adjusted?
Unfortunately the lumen level cannot be adjusted. Our customer service department will contact you.

Can the lamp be adjusted for length of time the light stays on when the PIR is activated?
The Light when the PIR is activated will stay on for 30 seconds to a minute. And will continue this if the PIR is attracting movement. This time can not be adjusted. This fixture also has an override setting, where the light can stay on for 5 hours.

What is the height of the light from the centre of the fitting?
The height from the centre of the fitting to the top of the light is 18.5cm.

on the PIR version, can the light be switched on manually ie does it have an over ride?
This has a manual override operation which can be activated by switching the light off-on-off-on by using the fused spur switch. This will switch the light on for a period of 5 hours.

Is this compatible with other E27 Edison Screw type bulbs (CFL for example?)
The supplier does not recommended that a CFL is used with this fitting as it has a Sensor.

Availability: IN STOCK 2-3 working day dispatch
