Subtle low-level recessed wall ighting with a 1w high power LED. With its square design and faceted reflector, which is great for casting light down and out. Designed for installation into plasterboard, a frame is available to aid installation in masonry walls that can be plastered into place.

Choose silver or white bezel, both have a matt silver fluted reflector inside for reduced glare.

Ideal installed along corridors and stairways.

We suggest that drivers are located remotely where access can be gained if repair or replacement is required. Requires an overall recessing depth of 45mm minimum.

Total circuit wattage should not exceed approximately 80% of rating of the driver.

Offered here in 3000°k (Warm white)

Requires 350mA LED driver and to be wired in series.

Cut out: Height: 81mm x Width: 69mm.

Number Of Lamps	1
Lamp Type	Long Life LED Light Source
Part L Compliant Luminaire	No
Lamps Included	Yes
Dimmable?	No
Total Wattage	1w
Width	90mm
Height	90mm
Suggested Void Depth	38mm
Construction	Aluminium - Powder Coated
Wiring Details	Class 3 - Requires a low voltage supply
Driver	No driver or transformer is supplied with this fixture (sold separately)
PDF Document(s)	Installation Help

We are moving in a new house where the staircase is already built. We would like to add some led spotlights. Is it possible to happen?
Putting low level lights in after the staircase and walls are built is possible, but may be a little messy. We do offer a design service, you could take some photographs and send them to us so we could advise you on what other solutions may be used.

Are these dimmable? What does K mean? eg 3000k
K is short for kelvin and 3,000 degrees Kelvin is a warm white light. Sorry if this was not clear. It’s very hard, due to the low load, to dim LED fixtures, but it is easier when a number of lights are powered by a larger (dimmable) power supply. Do contact us with details of you project, we will be happy to assist with the design.

We'd like to install these in our new build: do we need a separate driver for each fitting, and can they be triggered by a PIR?
These fittings are 1 watt each, and so if using the 3-way connector you can connect 3 fitting to one 3 watt power supply. In theory, there is no reason as to why these couldn't be controlled by a PIR. You would need to make sure that the relevant PIR can work with LED and have a low minimum load.

We are looking to install the lights in a staircase where you can walk past on ground level. When looking up at the lights the bulb inside the light mustn't catch the eye. Would these ones work well in that respect? Do you have any others that are similar but smaller in size?
Yes these would work in your instance, and light will not be in the eye when walking past. The lamp is covered and light is directed downwards. This is one of our smaller fittings.

LED Scoop for Low Level Glare-Free Lighting

Great for Lighting Stairs or Walkways
