LED Replacement Downlight for R63 & R80 Fire & IP65 Rated

Works with Existing Apertures (Holes) from 63mm to 130mm

Suitable for Zone 1 - protected from water jetsClass 2 – This fitting is double insulated and does not require an earth.Yes, this product is dimmable - See the specifications tab for more detailsSuitable for Bathroom Zones 1,2 and 3Bulbs IncludedIncludes integral driver/transformer suitable for 230 - 240v supply

Kelvin Chart

Product Ref: 41420

£34.28 inc VAT

Have you cut the hole too big? Need to replace a large old fashioned mains R63 or R80 downlight? This is the easiest and most modern answer to your dilemma.

This solution uses a dedicated LED SMD chip fixture and an oversize bezel making it suitable to cover holes left by large older style downlights.  Will work with existing apertures (holes) from 63mm up to 130mm.

The LED light component uses a 8w chip in two colours:

  • 3000°k 580 lumens
  • 4000°k 640 lumens

Each has a reflector giving a 40º beam making it a valid alternative to a 50w halogen lamp. Over 25,000 hours lamp life.

The LED light component also makes use of an intumescent seal to provide fire protection. In the event of a fire or high temperatures, this substance swells and stops fire from entering the ceiling void for up to 90 minutes.Offered in three finishes - white, polished chrome or brushed chrome.

IP65 rated so dust tight and offering protection from water projected from a nozzle. This is a downlight that could be installed in many areas in the home especially the bathroom.

Complete with LED driver which is fully dimmable on most leading and trailing edge dimmers that can handle the lower loads of LED lamps.

We also offer a dimmer module that will replace the dimmer inside your switch plate if your existing dimmer is incompatible.

This will operate a single downlight or a larger quantity.

Lamp TypeLong Life LED light source
Lumens Per Watt73
Lamps IncludedYes
Dimmable?Yes - on trailing edge (reverse phase dimmers)
Max Wattage8w
Total Wattage8w
Width180mm
Suggested Void Depth110mm
ConstructionMetal
Wiring DetailsClass 2 - Double Insulated - Requires no Earth Connection
IP RatingIP65
DriverIncludes integral driver/transformer suitable for 230 - 240v supply
Availability: IN STOCK 2-3 working day dispatch
We offer free delivery on orders over £50 to most UK Mainland Addresses
Product Code
Product Title

Price
Quantity
Choose your product
KITRICOSWWW
White 3000°k SMD Oversize Downlight
£34.28
£28.57 exc VAT
KITRICOSWCW
White 4000°k SMD Oversize Downlight
£34.28
£28.57 exc VAT
KITRICOSCWW
Chrome 3000°k SMD Oversize Downlight
£34.28
£28.57 exc VAT
KITRICOSCCW
Chrome 4000°k SMD Oversize Downlight
£34.28
£28.57 exc VAT
KITRICOSBWW
Brushed Chrome 3000k SMD Oversize Downlight
£34.28
£28.57 exc VAT
KITRICOSBCW
Brushed Chrome 4000k SMD Oversize Downlight
£34.28
£28.57 exc VAT
