Double Insulated Bathroom Lighting
If your lighting circuit does not have an adequate earth you can either have your wiring upgraded to incorporate an earth or use lighting that is double insulated.
Double-insulated lighting, also known as Class II lighting, is designed for enhanced safety, particularly in situations where an electrical ground (earth) connection may be lacking or unreliable. Scroll down for more information on double insulated lighting and reasons why you might need to use double-insulated lighting:
When considering lighting for areas with increased moisture or in locations where grounding might be uncertain, opting for double-insulated fixtures is a prudent choice to prioritize safety. But always follow local electrical standards and regulations to ensure that your lighting installations meet the necessary safety standards.
Adjustable IP44 Fire-Rated Bathroom Downlight - Dimmable
6 Options£41.20
Low Glare Matt White Recessed Downlight - Glass Sealed to IP44
4 Options£41.30
White Surface Mounted IP44 Bathroom Safe Ceiling Light
£43.95
Fire Rated Low Profile Downlight with Variable Colour Plus White Lamp
10 Options£44.00
- Sale
- 48% OFF
Square IP65 Rated Surface Mounted Downlight
3 Options£48.00
Low Profile Surface Mounted Downlight - Automatic Switching via Microwave Sensor
2 Options£53.52
- Sale
- 40% OFF
LED Surface Mounted Spotlight - Small and Subtle or Larger with Punch
5 Options£55.00
Round Opal Glass Bathroom Ceiling Light on Drop Stem
2 Options£56.00
- Sale
- 9% OFF
Bathroom IP44 LED Wall Light with Cabinet Bracket
2 Options£59.00
Square LED Panel Ceiling Light with Built-in Dimmer - IP54
2 Options£59.95
Chrome Curved LED Shaver Socket Light with Pullcord - Width 522mm
£66.00
Affordable Chrome Over Mirror LED Bathroom Wall Light
3 Options£68.99
Satin Brass and Clear Glass IP44 Bathroom Wall Light
£71.30
Tubular Bathroom Wall Lights - Single Mirror Bracket
£73.80
Double Insulated Bathroom Lighting - Class 2
Double insulated Class 2 electrical equipment has all exposed metalwork separated from the conductors by at least two layers of insulation, so that the metalwork cannot become live. There is no earth connection in the lighting and often manufacturers specify that no earth shall connect to the fitting. Your safety depends upon the integrity of the two layers of insulation. British double insulated equipment is marked with the double insulated logo (one square inside another), states “DOUBLE INSULATED” or Class II.
So, why would you require double insulated lighting? Here are the four reasons why you, or your electrician, requires double insulated lighting:
- You have no earth present in your lighting circuit
- The earth present on your circuit is inadequate or insufficient
- Your electrician cannot cross bond between your lighting and other electrical items in the bathroom.
- Your electrician cannot route an earth cable directly to your lighting because of existing decoration or tiling. References: IEC 61140: Protection against electric shock — Common aspects for installation and equipment. International Electrotechnical Commission. 2001. (formerly: IEC 536-2: Classification of electrical and electronic equipment with regard to protection against electric shock, 1992)
