Galvanised Soffit Downlight For LED lamps - Adjustable wallwashing

15 year guarantee - great for fit and forget exterior wallwashing

Protected from water spray i.e. rainClass 2 – This fitting is double insulated and does not require an earth.Bulbs Not Included

Product Ref: 3560

£27.76 inc VAT

A very popular recessed downlight, adjustable and offered in a robust galvanised zinc finish. Provides long-life, maintenance-free. service as a soffit downlight for washing the exterior walls of your building.

Accommodates mains LED lamps with a GU10 base - no transformers or drivers required.

Tilt adjustment allowing more flexibility and direction as to where the light is placed. Offers up to 35º adjustment great for highlighting particular areas of a building or providing interest through washing walls with light.

Designed for use with a mains GU10 base lamp up to 35 watts maximum. LED lamps are a good investment when used at high level.

IP23 rated providing protection from the British weather. Ideal for use in coastal areas with a 15 year guarantee.





Number Of Lamps1
Lamp TypeGU10 Base Mains Lamps
Lamps IncludedNo
Max Wattage50w
Total Wattage50w
Width80mm
Height65mm
Cut-Out Diameter72mm
Wiring DetailsClass 2 - Double Insulated - Requires no Earth Connection
IP RatingIP23
GU10 COB Warm White - 7W LED Lamp
JGGUCOB7WW
GU10 COB Daylight White - 7W LED Lamp
JGGUCOB7CW
GU10 Osram 2700ºk 5.3w Dimmable LED
RADPPAR1650ADV2700
GU10 Osram 3000ºk 5.3w Dimmable LED
RADPPAR1650ADV30
GU10 Osram 4000ºk 4.6w Dimmable LED
RADPPAR1650ADV40
GU10 COB Warm White - 5W LED Lamp
JGGUCOB5WW
GU10 COB Daylight White - 5W LED Lamp
JGGUCOB5CW
GU10 4.6 Watt Warm White Lamp - Osram LED Star
RADPPAR1650
Click here to choose your bulbs

Would this light be suitable for a conservatory fascia? I'm looking for a light that will cast a beam towards the garden but also the path below. The soffit isn't wide enough to accommodate lights but the fascia probably is. Is this light provided with a dimmer switch? And is it possible to have 5 or 6 lights on the same dimmer switch?
This can be used in a conservatory fascia when used with an LED lamp. These are a mains downlight, you can have a number of downlights on an inside dimmer switch. This listing is for the downlight only, Dimmable LED lamps and a dimmer switch would need to be bought separately.

What's the maximum soffit thickness that these lights will fit?
Maximum ceiling thickness is around 20mm.

Is this suitable to run off a mains circuit so no transformers are needed? I want to create a run of eight through the eaves but also need these to be easy to remove and replace, if necessary in the future, without having to take the larch cladding in the soffits off. Do they have clips so pull down quite easily?
This fitting does run off the mains and does not require a transformer. Lamp change is easy, and they do have clips. We would recommend using LED lamps as they have a much longer lamp life.

Are these galvanised down lights suitable for a coastal location?
Yes these downlights are perfect for coastal locations, they even have a 15 year guarantee against corrosion.

Is the tilt on these lights fixed or can it be adjusted?
The tilt is adjustable up to 45 degrees

Can this product be used in Denmark? Can it be ordered from you?
This fitting can be used in Denmark, you can order from us, Place your order online and a sales team will be in touch with a delivery cost.

do you not stock a similar item that is finished in chrome?
If only a small adjustment is needed, we have these that are finished in chrome.

My soffit is 50mm thick, would I be able to fit these spots?
This tilted downlight could not be used in a soffit that is 50mm thick because the clips that hold it in place are simply not big enough.

Does this product need a transformer?
This product does not need a transformer.

Availability: IN STOCK immediate dispatch
We offer free delivery on orders over £50 to most UK Mainland Addresses
Product Code
Product Title

Price
Quantity
Choose your product
NX20299931
Galvanised Soffit Downlight For LED lamps
You save £11.90
£27.76
£23.13 exc VAT
